The fin tube spacer, also named as fin tube support, is hold in the fixed position for long length fin tubes, especially for L Fin Tube, G Fin Tube and Extruded Fin Tube. The supports are applied to maintain the tube in right position without damaging the aluminum fins. They allow direct contact between tubes or between a tube and a tube supporting beam.
We have various kinds of fin tube spacer.
Divided by shape, the spacer has round circular shape, square shape, hexagonal shape, octagonal shape, rectangular shape and continuous hexagonal shape,etc.
Divided by material, the fin tube spacer can be made of aluminum, aluminum alloy, stainless steel, copper, copper alloy and zinc coated carbon steel plate.
Divided by sizes, our fin tube spacer has at least 10 sizes, can fix many size of fin tubes, such as for tube OD25.4mm with fin OD57.15mm, base tube OD31.8mm with fin OD63.5mm, base tube OD38.1mm with fin OD69.5mm, etc.
If our current fin tube spacer size not suitable for your fin tube, we can open new mould and tailor the exact right fin tube spacer for you. Sample can be provided as per client’s drawing for approval first before mass production.
For quality, pictures for each dimension size will be provided together with package details. We do accept the third party inspection such as BV, TUV, SGS to come and check the quality.
As a professional fin tube manufacturer, we can supply the fin tubes, fin tube spacer separately or fin tube fixed with spacer at our factory. We have exported lots to international markets.
If you have requirement for fin tube fixed with tube spacers, kindly send us the drawing to show the details and position of the tube spacer and we will deliver the goods to make you satisfied.
Have a glance at our aluminum fin tube also.
Fin Type | Base Tube Material | Fin Material |
Extruded Fin Tube | Aluminum Aluminum Alloy Seamless carbon steel tube Welded carbon steel tube Stainless steel seamless tube Stainless steel welded tube Nickel Alloy Tube Copper and copper alloy Titanium | Aluminum Al1050 Aluminum Al1060 Aluminum Al1100 Aluminum Al3003 Aluminum Al6063 |
****The extruded fin can be with or without serrate. | ||
L/LL/KL Fin Tube L Type Perforated Fin Embedded G Fin Tube | Aluminum Aluminum Alloy Seamless carbon steel tube Welded carbon steel tube Stainless steel seamless tube Stainless steel welded tube Nickel Alloy Tube Copper and copper alloy Titanium | Aluminum Al1050 Aluminum Al1060 Aluminum Al1100 Copper |
FAQ
Q: Are you trading company or manufacturer?
A: We are a factory, specializing in fin tubes fabrication and heat exchanger tube trading since 2012.
Q: What is your main business?
A: DR(Extruded) Fin Tube
L Foot Tension Fin Tube
Double L Fin Tube
Knurled L Fin Tube
Grooved G Fin Tube
High Frequency Welded Fin Tube
Laser Welded Fin Tube
Heat exchanger tube and U Bent Tube
Q: How many staff in your company?
A: Totally we have 60 staff.
Q: How do you control your quality?
A: We always put quality as the most important thing for customers, and we control the quality from raw material inspection, production checking to water pressure test and strength test. Also the third party can be authorized to check.
Incoming inspection report for bare tube & strip.
Mill test certification for bare tube
Mill test certification for fin
Mill test certification for finned tube
Finned tubes dimension & visual inspection reports
