Stainless steel industrial welded pipe is a hollow long round steel, mainly widely used in petroleum, chemical, medical, food, light industry, mechanical instrumentation and other industrial pipelines and mechanical structural components.
According to ASME SA249 Specification, TP304 stainless steel tube is welded. So usually we also say ASME SA249 TP304 Welded tube. Comparing with TP304 Seamless tube, the SS304 Welded tube can save cost. Nowadays, more people use SA249 SS304 Welded tube to replace SA213 TP304 Seamless tube, especially in the filed of heat exchanger, boiler and condenser system.
In addition, when the bending and torsional strength are the same, the weight is lighter, so it is also widely used in the manufacture of mechanical parts and engineering structures.
According to different manufacturing processes, it can be divided into several basic types: hot rolling, extrusion, cold drawing and cold rolling, and can be divided into round tubes and special-shaped tubes according to the cross-sectional shape.
For steel pipes under fluid pressure, hydraulic test or Eddy Current test is required to check their pressure resistance and quality. It is qualified if no leakage, soaking or expansion occurs under the specified pressure. Some steel pipes also need to be crimped according to standards or requirements of the buyer, such as Flaring test and flattening test.
Chemical Composition of SA249 SS304 Welded Tube
Carbon | Silicon | Manganese | Phosphorus | Sulfur | Chromium | Nickel | Iron |
≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤0.030 | 18-20 | 8-11 | Balance |
Production process
Raw material strip - slitting - welding pipe - heat treatment - straightening - straightening - trimming - pickling - hydraulic test - inspection (printing) - packaging - delivery
Material of stainless steel welded pipe: 304/304L, 316L, 310S, 321, 904L, 2205/2507.
Welding Method: TIG, PAW, SAW, one of them all combined.
Executive Standard: GB/T12771-2008, ASME SA249, ASTM A1016M.
Production Capacity
OD12~325mm with tolerance ±0.3mm. Custom Size/Stock Size has 12.7mm, 15.875mm, 19.05mm, 25.4mm, 31.8mm, 38.1mm, 50.8mm, 76.2mm.
Tube Wall thickness: 0.5~8mm with tolerance ±10% or as request. Both average thickness and minimum thickness are accepted. Normal thickness we have is 0.71mm, 0.89mm, 1.0mm, 1.25mm, 1.65mm, 2.11mm and 2.77mm for international market.
Length: 20~30meters with positive tolerance 3-5mm
Delivery Condition:
Annealed and Pickled (AP), Polished, Bright Annealed (BA), Cold Drawn, Mirror Polished.
Surface Finish:
Mirror Finish ASTM A249 Standard Tube or Customized Finish as per client’s requirement.
Technique:
ASME SA249 Welded Austenitic Steel Cold Drawn, Cold/ Hot Rolled, Extrusion Welded Tube.
Quality Control:
With ISO9001 quality management system certification and pressure pipeline component manufacturing license, has a sound quality inspection and control system, equipped with industrial CT, chemical analysis, eddy current inspection, hydraulic test, air tightness test, universal testing machine and other inspection links or detection equipment.
Mill Test Certificate is with EN10201 3.1 certified. We also accept inspection from third party such as SGS, BV, TUV to get EN10204 3.2 certificate.
Package: Woven bags, wooden case or steel frame with plywood case for long length.
Sea worthy export packing as customer’s request.
Application
Construction Industry
Food and Medical Industry
Waste Pollution Treatment
Oil and Gas
Paper Making
Power Plant
Heat Exchanger
Condenser
Marine, Fluid, gas and oil industry. etc.
With complete sets of production lines, including auto welding machines and bright annealed devices, we can meet various kinds of requirement and additional value service, such as bright annealing welded tube, cold drawn precision tube and U bend welded tube.
FAQ
Q: Are you trading company or manufacturer?
A: We are professional manufacturer of steel tube, stainless steel tube and also finned tubes.
Q: Do you provide samples in free?
A: Yes, samples in short cut can be provided freely but with courier cost collected. Or customer pay us the courier cost first and then we return it from future orders.
Q: Do you accept the third party inspection?
A: Yes, we always cooperate with SGS, TUV, BV and other inspection party customer pointed.
Q: How your company guarantee the quality?
A: Each product is manufactured by certified operators under company’s strict quality policy, we have QA/QC standard and can issue warranty annex to our customers.
