Product Introduction
Fin Type: Extruded(DR)
Tube Material: Aliuminum 1100, Aluminum 1060... ...
Tube OD: 10-50mm
Wall Thick: 0.8-5mm
Fin Material: Aluminum 1100, Aluminum 1060... ...
Fin Hight: 8-15.875mm
Fin Thick: 0.2-1mm
Fin Pitch: 8-18FPI
Application: Heaters, Coolers, Condensers, Heat Exchangers...
During the manufacturing of mono aluminum finned tube, we take the method of integral extruded, which make base tube and fins performs a very strong bond. This process can ensure there is almost no air gap or non contact areas between base tube and fin.
In order to avoid minsunderstanding during your inquiry, please provide the following datas:
1. The material of base tube and fin
2. The quantity of finned tubes you need
3. Base tube OD * Wall Thick * Length(Total length and unfinned length at two side)
4. Fin OD * Fin Thick * Fin Pitch
